Vision V1.2 (sale for partners only)

Name: Vision V1.2 (sale for partners only)
Brand: Stingbee
Price: 5130.00 UAH
Availability: OutOfStock

Top

New

Код: Vision V1.2

Виробник: Stingbee

Під замовлення

Комплект Vision Board

5130.00 грн.

Знайшли дешевше ?

Опис Vision V1.2 (sale for partners only)

Тільки комплект для розробки власного програмного забезпечення

Доступні початкові коди: U-Boot, Linux kernel 4.19, Buildroot, опційно підтримка Debian та Ubuntu 20.04

Специфікація

CPU	Quad-core 32-bit ARM Cortex-A7, RISC-V MCU, up to 1.5GHz 250ms Fast booting
GPU	ARM Mali-G610 MP4 quad-core GPU, Support OpenGL ES3.2 / OpenCL 2.2 / Vulkan1.1, 450 GFLOPS Support rotation , x-mirror , y-mirror Support alpha blending Support scale down/up
NPU	Up to 2.0 TOPs Support 8-bit/16-bit operation Support TensorFlow, TensorFlow lite, Pytorch, Caffe, Mxnet, Darknet, Onnx
ISP	14MP ISP, 3-frame HDR
VPU	4K H.264/H.265 30fps video encoding, 3840×2160@30fps + 1080@60fps encoding 4K H.264/H.265 30fps video decoding, 3840×2160@30fps encoding + 3840×2160@30fps decoding
RAM	LPDDR3 (512MB/ 1GB optional)
Storage	eMMC (8GB/16GB/32GB/64GB optional) SDIO 3.0 interface for SD card
Power	Core board supply voltage 5V (voltage tolerance ± 5%)
OS	Linux (Buildroot+Ubuntu20.04+Debian)
Size mount	30.5x30.5mm
Power consumption	Min:≈0.15W(5.0V/30mA) Normal:≈0.75W(5.0V/150mA) Max:≈3.25W(5.0V/650mA) + (USB ext 5.0V/500mA)
Environment	Operating temperature: -20℃～70℃ Operating humidity: 10%～90%RH (non-condensing)
Video Input	2 * MIPI CSI (or LVDS/sub LVDS) Support simultaneous input from 2 cameras: 2 * MIPI CSI (or LVDS/sub LVDS)
Video Output	1*MIPI-DSI (up to 1080P @ 60 FPS)
USB	1USB 2.0 HOST, 1USB 2.0 OTG
Other	3UART, 2I2C, 2*LEDs, GPIOs
